| 원래 장소: | 중국 |
| 브랜드 이름: | Wolvesteam |
| 인증: | CE |
| 모델 번호: | JM311025-4 |
| 최소 주문 수량: | 1 |
|---|---|
| 가격: | negotiated price |
| 포장 세부 사항: | 상자 520×580×330 mm |
| 배달 시간: | 30 일 |
| 지불 조건: | L/C (신용장), 전신환 |
| 공급 능력: | 100pieces/month |
| 타입: | 방수 조정가능한 | 구획 빈도: | 20-2500MHz |
|---|---|---|---|
| 총 출력 전력: | 300W | 범위를 움직이지 않게 하기: | 300m까지 주어진 지역에 있는 힘 신호에, 움직이지 않게 하는 반경 아직도 달려 있습니다 |
| 전원 공급기: | 60Hz에 50, 240V AC에 100 | 소프트웨어 기능을 감시하십시오: | 각 기계 작동 국가를 전망하는 리모트 |
| 장점: | 각 밴드는 RF 전원 출력 수준을 조정하거나 다른 밴드의 가동 좌우 없이 끌 수 있습니다 | 응용 범위: | 군대, 형무소, 경찰, 불발탄 처리 |
| 강조하다: | IED 차량 신호 방해기,2500MHz 차량 신호 방해기,무선 제어 조정 신호 방해기 |
||
The High Power IED Jammer shall have the following feature. . Portability.
It shall be lightweight, man portable and comfort to use. . Safety of
Usage. It shall be safe for use. . Simplicity. It shall be simple to set-up
and easy to use. Robustness. It shall be strong and robust to
withstand crush, shock and vibration. Transportability. It shall be
easily transportable by hand, Remote Explosive Ordnance Disposal
Vehicle (REODV) or on any EOD transport vehicle. Maintenance. It
shall be simple to maintain during storage and use. Protection. It
shall be protected from Radio Frequency and Electromagnetic
interference. Reliability. All components shall be highly dependable
to perform its required functions when used in any environment
throughout its shelf life. Environment. It shall be fully tropicalization
and not easily affected by the ingress of moisture or dust.
Advantages and Features:
• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.
Specification
| Output Interface | Output Frequency | Output power |
| CH1 | 20-100MHz | 50w |
| CH2 | 100-500MHz | 50w |
| CH3 | 500-1000MHz | 50w |
| CH4 | 1000-1500MHz | 50w |
| CH5 | 1500-2000MHz | 50w |
| CH6 | 2000-2500MHz | 50w |
| Total RF Power | 300W | |
| Power supply | AC220V | |
| Shielding area | 300m @ according to signal density of mobile network | |
| Jammer Module Number | 6 | |
| Power consumption | 1000W | |
| Weight | 25.00 Kg | |
| Size (length x wind x high) | 320×380×230 mm | |
| Humidity | 30%-95% | |
| Running Temperature | -20 to +55 Celsius Degree | |
| Battery Working Time (Option) | 2 or 3 hours | |
Accessories
Products Application Fields
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
