| 원래 장소: | 중국 |
| 브랜드 이름: | Wolves Team |
| 인증: | CE,ISO |
| 모델 번호: | WT805712 |
| 최소 주문 수량: | 1 |
|---|---|
| 포장 세부 사항: | 상자 |
| 배달 시간: | 3-4 주 |
| 지불 조건: | L/C, D/P, T/T, Western Union |
| 모니터 소프트웨어 기능: | 각각 기계의 원격 제어 스위치 장치. | 배터리 작동 시간: | 2-3 시간 |
|---|---|---|---|
| 방해 범위: | 최고 300까지 미터 | 재료: | 알루미늄 합금 |
| 이점: | 업그레이드 모듈 설치를 위해 계속하세요 | 사용: | VIP 보호에 경찰 사용 |
| 포장: | 상자 | 크기: | 580 × 580 × 680mm |
| 강조하다: | VIP protection vehicle signal jammer,20-6000Mhz vehicle signal jammer,vehicle signal jammer installation module |
||
This High Power Full Band Vehicle Military Convoy Protection Roof Mounted Jammer System is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.
It is designed to protect military and country leaders VIP team, EOD, police investigation and arrest prisons, government buildings, wireless remote bomb and some occasions for a temporary protection to respond to some emergencies.
This Bomb jammer can cover, continuously and simultaneously, all the RF communication Frequencies can custom for 20-6000MHz. It will be the best solution to defend a VIP convoy for and features rapid deployment and set up for military bases, important sports events, international summits, and other high profile events.
The Bomb jammer is a fully portable multi-band PLL or DDS Jamming system, and designed with a ruggedized trolley type case for high mobility. This device is configured more than 12 different jamming modules, and the jamming frequency can be more than 12 Bands. This High power Jammer 12 bands jamming frequency modules can provide up to 1200 Watt output power maximum.
The Bomb jammer is very easily installed and operated. The device can be powered by AC mains or a suitable DC power source. The general design of the system meets military requirements and international quality standards.
| Output Interface | RF Frequency Band(MHz) | Application | RF Output Power (Watt) |
|---|---|---|---|
| CH1 | 20-80 | Toys HM Remote control | 50W |
| CH2 | 135-175 | Walky-talky VHF/Lojack | 50W |
| CH3 | 400-480 | Walky-talky (UHF400) | 50W |
| CH4 | 790-826MHz | 4G/GSM850 | 50W |
| CH5 | 925-960MHz | GSM900 | 50W |
| CH6 | 1800-1880MHz | DCS | 50W |
| CH7 | 2100-2170MHz | 3G | 50W |
| CH8 | 2570-2690MHz | 4G WIMAX | 50W |
| CH9 | 3400-3600MHz | 5G | 50W |
| CH10 | 2400-2500 | WIFI & Bluetooth | 50W |
| CH11 | 5700-5800 MHz | WIFI 5.8G | 50W |
| CH12 | 1560-1625MHz | GPSL1 | 50W |
| Option | 20-6000MHz | Option | Option |
| Total RF Power | 600Watt | ||
Power supply: Input AC230V
Shielding area: 100-300m @ according to signal density of mobile network
Jammer Module Number: 12
Cooling System: Systematic Smart Cooling System
System Protection: VSWR, Over-voltage, Over-current
Jamming Source: PLL Source Technology
Remote Control (Option): Full System Operation Control
Antenna Type: High Gain Omnidirectional Antennas
Number of Antennas: 12
Power consumption: 600W
Power Supply Source (Option): Additional AC Alternator (600W) or Additional DC Generator (+24 VDC/25A)
Weight: 35.00Kg
Size (length × wind × high): 580×580×680mm
Humidity: 30%-95%
Running Temperature: -20 to +60 Celsius Degree
High-quality jammers have a wide range of applications in various fields including Military Units, Prisons, Police departments, Bomb Disposal units, and Security Services.
These devices are also utilized in government institutions, Gas Stations, Guard posts, Schools, Churches, Meeting rooms for invigilation purposes, Libraries, Hospitals, Theaters, Classrooms, and other critical locations and situations.
No. Because the electromagnetic signal sent by jammer are totally used in the band that regulated by government and just have interception effect to cell phone communication.
Please do not need to worry about it. The intensity of electromagnetic signal sent by jammer is in compliance with the national standard of environmental electromagnetic wave health. The signal sent by jammer is relatively small and unharmful to human body according to the testing result. Meanwhile,this device just damages the receiving condition to the cell phone and makes the normal connection between cell phone and base station impossible. Therefore, no damage will occur on cell phone itself.
Yes. Generally speaking, outdoor signal is bigger than the indoor signal. Thereby, the shielding effect is worse outdoor. Strictly speaking, whether using indoor or outdoor, the effective distance of interference is related to the surrounding around, for example the distance between different base stations,positions of installation etc.
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
|---|---|
| Payment Terms | 50% advance, 50% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
