| 브랜드 이름: | Wolves Team |
| 모델 번호: | WT805712 |
| MOQ: | 1 |
| 배달 시간: | 3-4 주 |
| 지불 조건: | L/C, D/P, T/T, Western Union |
This High Power Full Band Vehicle Military Convoy Protection Roof Mounted Jammer System is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system. It is designed for protecting military and country leaders VIP teams, EOD, police investigation and arrest prisons, government buildings, wireless remote bomb threats, and providing temporary protection in emergency situations.
Additionally, this Bomb jammer can cover, continuously and simultaneously, all RF communication frequencies customizable from 20-6000MHz. It serves as the ideal solution for defending VIP convoys with its rapid deployment and setup capabilities, making it suitable for military bases, important sports events, international summits, and other high-profile gatherings.
The Bomb jammer is a fully portable multi-band PLL or DDS Jamming system, housed in a ruggedized trolley type case for high mobility. It consists of more than 12 different jamming modules that can operate across more than 12 bands. This High Power Jammer with 12 bands jamming frequency modules can deliver up to 1200 Watt maximum output power. Installation and operation are straightforward, and the device can be powered by AC mains or a suitable DC power source. The system design complies with military requirements and international quality standards.
| Output Interface | RF Frequency Band (MHz) | Application | RF Output Power (Watt) |
|---|---|---|---|
| CH1 | 20-80 | Toys HM Remote control | 50W |
| CH2 | 135-175 | Walky-talky VHF/Lojack | 50W |
| CH3 | 400-480 | Walky-talky (UHF400) | 50W |
| CH4 | 790-826MHz | 4G/GSM850 | 50W |
| CH5 | 925-960MHz | GSM900 | 50W |
| CH6 | 1800-1880MHz | DCS | 50W |
| CH7 | 2100-2170MHz | 3G | 50W |
| CH8 | 2570-2690MHz | 4G WIMAX | 50W |
| CH9 | 3400-3600MHz | 5G | 50W |
| CH10 | 2400-2500 | WIFI & Bluetooth | 50W |
| CH11 | 5700-5800 MHz | WIFI 5.8G | 50W |
| CH12 | 1560-1625MHz | GPSL1 | 50W |
| Option | 20-6000MHz | Option | Option |
| Parameter | Specification |
|---|---|
| Total RF Power | 600Watt |
| Power supply | Input AC230V |
| Shielding area | 100-300m @ according to signal density of mobile network |
| Jammer Module Number | 12 |
| Cooling System | Systematic Smart Cooling System |
| System Protection | VSWR, Over-voltage, Over-current |
| Jamming Source | PLL Source Technology |
| Remote Control (Option) | Full System Operation Control |
| Antenna Type | High Gain Omnidirectional Antennas |
| Number of Antennas | 12 |
| Power consumption | 600W |
| Power Supply Source (Option) | Additional AC Alternator (600W) or Additional DC Generator (+24 VDC/25A) |
| Weight | 35.00Kg |
| Size (length × width × height) | 580×580×680mm |
| Humidity | 30%-95% |
| Running Temperature | -20 to +60 Celsius Degree |
High quality jammers are extensively utilized in various sectors including:
These devices serve essential functions in maintaining confidentiality and security in locations where control or restriction of communication signals is crucial.
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
|---|---|
| Payment Terms | 50% advance, 50% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
